Product Overview
Mettlead Truck Shacman F2000 6X4 Dump Truck is a classic and cost-effective heavy-duty tipper lorry specially designed for urban construction, road renovation, mining transportation and earthwork projects. Adopting mature and reliable heavy-duty manufacturing technology, this 310HP dump truck is equipped with a professional Weichai power system, heavy-duty drive axle and reinforced dump cargo box. It features strong climbing performance, stable heavy-load operation and excellent terrain adaptability. With durable overall structure and low maintenance cost, it has become the mainstream reliable transportation equipment for medium and heavy-duty engineering hauling projects worldwide.
Extended Description
The Shacman F2000 6X4 tipper truck is powered by a Weichai WP10.310E32 diesel engine, with a maximum power of 310HP and peak torque of 1250Nm. The engine outputs strong and stable low-speed torque, which can easily cope with heavy-load starting, steep slope climbing and rugged road driving, fully adapting to high-intensity engineering operation scenarios. Matched with a Fast 9-speed manual transmission system with high-strength gear structure, it realizes smooth and precise gear shifting, effectively improving power transmission efficiency and ensuring stable power output under complex working conditions.
The whole vehicle adopts a classic 6×4 all-wheel drive configuration, equipped with a 16T MAN heavy-duty rear axle with a 5.92 professional speed ratio. The super load-bearing structure greatly improves the vehicle’s heavy-load durability and impact resistance. The standard 5.8-meter high-strength self-unloading cargo box is designed for efficient bulk material transportation, supporting rapid self-discharging of sand, gravel, earthwork, mineral materials and construction waste, which significantly improves engineering turnover efficiency.
In terms of safety and comfort, the vehicle is equipped with ABS anti-lock braking system and daytime running lights to ensure safe driving on rainy, slippery and complex road sections. The humanized cab is equipped with an air suspension shock-absorbing driver seat, independent air conditioning, electric windows and central locking system, creating a comfortable driving environment for long-term continuous operation. The 400L large-capacity fuel tank meets the endurance demand of long-distance and high-intensity engineering operations, reducing frequent refueling and improving overall work efficiency.
Key Features & Core Advantages
1. Powerful Weichai Original Power System
Equipped with authentic Weichai WP10.310E32 engine, with 310HP stable power output and 1250Nm super high torque reserve. The power response is sensitive, the explosive force is strong, and the power is sufficient under full-load climbing and heavy-load transportation conditions. The mature engine technology ensures low failure rate, stable operation and strong environmental adaptability, fully meeting the power demand of various harsh engineering scenarios.
2. Efficient & Stable Transmission Matching
Matched with Fast 9-speed heavy-duty manual gearbox, equipped with high-strength wear-resistant gear structure. It can realize smooth gear shifting and accurate power distribution whether in flat road cruising or rugged road climbing. The reasonable gear ratio design effectively reduces power loss, improves transmission efficiency, and ensures stable and efficient power output under long-term high-intensity operation.
3. 16T MAN Heavy-Duty Load-Bearing Structure
Adopts 16T MAN reinforced rear axle with 5.92 professional heavy-load speed ratio, with super load-bearing capacity and torsional resistance. The overall chassis is reinforced and optimized, matched with 11.00R20 / 12.00R20 thickened radial engineering tires, which has strong grip, wear resistance and impact resistance. It can operate stably for a long time on mining yards, muddy construction roads and bumpy mountain roads, with outstanding durability.
4. Large Self-Unloading Cargo Box & High Efficiency
Equipped with 5.8m large-capacity high-strength dump cargo box, with a rated load of 12.47 tons. The cargo box is made of thickened steel plate, which is firm and anti-deformation. The mature hydraulic self-unloading system supports fast lifting and discharging, realizing rapid unloading of bulk materials, greatly improving engineering transportation efficiency and shortening project construction cycle.
5. Long-Endurance & Low Operating Cost
Configured with 400L large-capacity fuel tank, which effectively extends single-operation cruising range and adapts to long-distance and high-frequency engineering operations. The optimized power matching and vehicle calibration realize low comprehensive fuel consumption. The mature and universal accessories greatly reduce later maintenance costs and vehicle downtime, with extremely high project economic benefits.
6. Comprehensive Safety & Driving Comfort
Equipped with ABS anti-lock braking system and daytime running lights to effectively avoid driving risks on complex roads and improve driving safety. The upgraded cab is equipped with air suspension seat, independent air conditioning, electric windows and central locking system. The spacious interior space and humanized configuration effectively relieve driver fatigue and ensure continuous and efficient operation of the vehicle.
Wide Application Scenarios
This Shacman F2000 6X4 heavy-duty dump truck is widely applicable to urban infrastructure construction, road renovation and expansion, mining material transportation, water conservancy and hydropower engineering, earthwork backfilling, construction waste cleaning and other medium and heavy-duty engineering scenarios. It is the preferred cost-effective transportation equipment for engineering contractors, mining enterprises and construction teams.
Full Detailed Product Parameters
Parameter Item | Detailed Specification |
Model | Shacman F2000 6X4 Dump Truck |
Brand | Shacman |
Drive Type | 6×4 |
Engine Model | Weichai WP10.310E32 |
Max Power | 310HP |
Max Torque | 1250Nm |
Transmission | Fast 9-speed Manual Gearbox |
Rear Axle | 16T MAN Heavy-duty Rear Axle |
Rear Axle Ratio | 5.92 |
Cargo Box Length | 5.8m |
Rated Payload | 12.47 Tons |
Fuel Tank Capacity | 400L |
Tire Specification | 11.00R20 / 12.00R20 Radial Tire (12pcs) |
Braking System | Air Brake + ABS Anti-lock System |
Safety Configuration | Daytime running lights, emergency warning lights |
Cab Configuration | Air suspension seat, A/C, electric window, central locking |
Unloading System | Hydraulic automatic self-unloading system |
Vehicle Condition | New Customized |
Drive Type | Left-hand drive / Right-hand drive (Optional) |
